The bench top CM-3700D spectrophotometer uses the latest technology for precision measuring that exceeds most industry color requirements even when scanning darker shades.

(Discontinued) CM-3700d Spectrophotometer

View our latest version of this instrument, the CM-3700A.

The CM-3700D Spectrophotometer is a bench top model that is precise and reliable. This device has a complete optical system that goes beyond industry standards along with aperture masks and a large sphere. Measurements are subjected to a high powered xenon flash to ensure the greatest level of accuracy. Depending on the application, users have the choice of switching between measuring areas; 25.4mm, 8mm, and 3x5mm.

The CM-3700D Spectrophotometer measures reflective colors with ease and can be switched from SCE and SCI effortlessly. This device’s UV cut filters allow the user to measure florescent colors via an automatic 1,000-step adjustment of UV light; this process provided excellent measurements of pulp, paper, and other florescent infused materials while transparent colors are effectively measured through diffused lighting. The impressive features of this device allow measurements to be taken form an array of materials including, but not limited to, textiles, plastics, kiln-fired materials, dyed items, food, and liquids.

The CM-3700D Spectrophotometer works well with Windows based computers via a USB connection. The device is compatible with a variety of Windows programs allowing for the easy editing and data management.

The CM-3700D Spectrophotometer is compatible the SpectrMagic NX software. The SpectraMagic software is user friendly and displays multiple, editable views of data results. Two or more secondary targets can be associated with targeted data from a primary target; this capability coincides with sophisticated QC applications like checking for color differences.

The software works on a drag-and drop platform which allows for easy interpretation after printing. For displaying information there is a variety of graph available along with preconfigured templates. There is also a status window in which users may view instrument information. Information compiled through older software is compatible with current software and can easily be transferred; all data is Excel exportable. Included with the software are a Color Tutorial and a Navigation Function to provide users with additional information.

CM-3700d Spectrophotometer

(Discontinued) CM-3700d Spectrophotometer

  • Highly accurate and reliable – utilizes state-of-the-art technology to make it one of the most reliable and accurate spectrophotometers available
  • Windows compatible – can be controlled from a computer with Windows software
  • Measurement area switching – users can choose between 25.4mm, 8mm, and 3x5mm measurement areas
  • Can measure reflective, fluorescent, and transparent color – using SCI/SCE switching, UV cut filters, and/or diffused lighting, reflective, fluorescent, and transparent colors can easily be measured
  • International standards – CIE, ISO, ASTM, DIN, and JIS are among the standards included in the CM-3700d
  • Xenon flash – enables the instrument to accurately measure even very dark shades

(Discontinued) CM-3700d Spectrophotometer

Illumination/observation system d/8 (diffused illumination; 8° viewing angle); SCI (specular component included)/SCE (specular component excluded) switchable; meets ISO and DIN standards for d/8 geometry; also meets CIE and ASTM standards for d/0 geometry. Transmittance: d/0 (diffuse illumination/0° viewing angle)
Detector Silicon photodiode array with flat holographic grating
Wavelength range 360nm to 740nm
Wavelength pitch 10nm
Half bandwidth Approximately 14nm average
Photometric range 0 to 200%; Resolution: 0.001%
Light source Pulsed xenon arc lamp
Measurement time 0.6 to 0.8 sec. (to start of data output)
Illumination/measurement areas Reflectance: Changeable between LAV, MAV, and SAV
LAV: Φ28mm illumination/Φ25.4mm measurement
MAV: Φ 11mm illumination/Φ8mm measurement
SAV: 5 × 7mm illumination/3 × 5mm measurement
Transmittance: Approx. Φ20mm
Repeatability When white calibration plate is measured 30 times at 10-sec. intervals after white calibration has been performed: ;
Spectral reflectance: Standard deviation within 0.05%
Chromaticity: Standard deviation within ΔE*ab 0.005
When black tile (BCRA Series II; reflectance: 1%) is measured 30 times at 10-sec. intervals after white calibration has been performed:
Spectral reflectance: 380 to 740nm: Standard deviation within 0.02%
360 and 370nm: Standard deviation within 0.04%
Chromaticity: Standard deviation within ΔE*ab 0.05
Inter instrument agreement Mean ΔE*ab 0.08 (typical) Average for 12 BCRA Series II color tiles. Max ΔE*ab 0.3 (corresponds to ΔEcmc 0.2) for any of 12 BCRA Series II color tiles compared to values measured with master body
Temperature drift Spectral reflectance: Within ±0.10%/°C
Color difference: Within ΔE*ab 0.05/°C
UV adjustment Computer controlled; continuously variable
Specimen conditions for transmittance measurements
Interface RS-232C standard; baud rates: 12,00, 2400, 4800, or 9600
Power AC 100V/120V/230V 50/60Hz (using included AC adapter)
Operating temperature/humidity range 13 to 33°C, relative humidity 80% or less with no condensation
Storage temperature/humidity range 0 to 40°C, relative humidity 80% or less with no condensation
Dimensions (W × H × D) 271 × 259 × 500mm (10-11/16 × 10-3/16 × 19-11/16 in.)
Weight 18kg (39.7 lb.)
Standard accessories White Calibration Plate; Target Mask (3 × 5mm); Target Mask (Φ8mm); Target Mask (Φ25.4mm); Zero Calibration Box; AC Adapter; RS-232C Cable (2m/6.6 ft., 9-pin, for IBM PC); Accessory Case CM-66
Optional accessories Color Data Software SpectraMagic NX; Transmittance Specimen Holder; Glass Cells (2mm, 10mm, 20mm); Plastic Cells (2mm, 10mm, 20mm); Transmittance Zero Calibration Plate; Color Tiles; RS-232C Cable (for IBM PC)

Specifications subject to change without notice.

(Discontinued) CM-3700d Spectrophotometer

Catalog Download: Download PDF (1.1MB)

Owner’s Manual: Download PDF (1MB)

Case Study: Clemson University: Understanding and Controlling Color Download PDF (2MB)
