The Specim IQ is designed for efficient and accurate hyperspectral imaging. This portable hyperspectral camera enables fast and effortless capture, processing, and visualization of hyperspectral data. It is perfect for lab work, fieldwork, and on-the-go hyperspectral imaging analysis, providing instant and critical decision-making information.

Hyperspectral Imaging Camera Specim IQ

The Specim IQ is a portable hyperspectral camera that offers a comprehensive solution for hyperspectral imaging. It combines measurement, data processing, and result visualization in one device. With its compact and battery-operated design, the Specim IQ can be used in various environments such as labs, industrial facilities, or even out in the field. It provides instant hyperspectral measurement and analysis with ease.

Unlike typical line-scan hyperspectral cameras, the Specim IQ has an integrated scanner, eliminating the need for an external scanner to facilitate target or camera movement during measurement. One of the standout features of the Specim IQ is its intuitive user interface. Even users with no prior experience in hyperspectral imaging can easily operate the camera, thanks to the user-friendly interface that guides them through the entire measurement process. Operating the Specim IQ is as simple as using a digital camera. Just point the camera at the target, define the settings, and start the measurement. The Specim IQ provides various modes, including the default recording mode for unprocessed hyperspectral data (raw and reflectance data) or the customizable application mode.

The Specim IQ hyperspectral camera is accompanied by the Specim IQ Studio PC software, providing users with a platform for developing and uploading their applications directly into the camera. Within the Specim IQ Studio, users can effortlessly manage the hyperspectral data and camera settings or even create models and reference spectrums, all in one convenient platform.

The Specim IQ, with its innovative and versatile functionalities, unlocks boundless possibilities for hyperspectral imaging. It not only enhances existing applications such as agriculture, food, medical science, and art but also paves the way for new and exciting fields of exploration.

Hyperspectral Imaging Camera Specim IQ

  • Hyperspectral + viewfinder camera
  • In-built scanner and motor
  • Embedded data processing unit
  • Operating software, Specim IQ Studio, for data acquisition and processing
  • Touch screen display and physical buttons
  • Lightweight and compact design with IP class protection
  • Various operational modes:
    • Default recording mode
    • Automatic Screening mode
    • Application mode (user definable)
    • Time lapse mode
    • Remote usage
  • USB and Wi-Fi connectivity
  • Rechargeable battery power supply

Hyperspectral Imaging Camera Specim IQ

Spectral cameraVNIR 400-1000 nm (CMOS)
Viewfinder camera5 Mpix
User interface SWBy Specim
StorageSD card (max: 32 GB)
Data FormatSpecim Dataset with ENVI compatible data files
Battery5200 mAh Li-Ion (Type 26650)
Operational timeAppx. 100 measurements (one SD card and battery)
Display & keyboard4.3 ” touch screen + 13 physical buttons
Camera interfaceUSB Type-C, Wi-Fi
Size207 x 91 x 74 mm (depth with lens 125,5 mm)
Weight (kg)1.3
F/number1.7
Wavelength band400-1000 nm
Spectral resolution FWHM7 nm
Spatial Sampling512 pix
Spectral bands204
Peak SNR> 400:1
Object distance    150 – ∞ mm
FOV31 x 31 deg
FOV at 1 m0.55 x 0.55 m
Temperature (operational)+5°C – +40°C
Humidity (operational)95% non-condensing

Hyperspectral Imaging Camera Specim IQ

Catalog Download: Download PDF (1.16MB)

Specim Products Catalog Download: Download PDF (2.41MB)

Video: Hyperspectral Goes Mobile – Vegetation Research



Video: Hyperspectral Goes Mobile – Food Analysis



Video: Hyperspectral Goes Mobile – Health Sector



Video: Hyperspectral Goes Mobile – Art Analysis



Video: Hyperspectral Goes Mobile – Crime Investigation



Specim IQ - Hyperspectral Imaging Camera
